inductive Square shape series Q80 Quick connector

inductive Square shape series Q80 Quick connectorسنسور القایی مجاورتی شکل مربع بیداک سری Q80 Quick connector

Model : Q80 Quick connector

Brand:Biduk

Product Features:

  • Product Catalog

    Model Installation type Detection distance Output polarity Voltage Connection mode Shell material Other instructions
    I1PF-Q8040N-O3U flush 40mm NPN NO 10-30VDC Quick connector PBT
    I1PF-Q8040N-C3U Flush 40mm NPN NC 10-30VDC Quick connector PBT
    I1PF-Q8040P-O3U Flush 40mm PNP NO 10-30VDC Quick connector PBT
    I1PF-Q8040P-C3U Flush 40mm PNP NC 10-30VDC Quick connector PBT
    I1PF-Q8040N-S4U Flush 40mm NPN NO&NC 10-30VDC Quick connector PBT
    I1PF-Q8040P-S4U Flush 40mm PNP NO&NC 10-30VDC Quick connector PBT
    I4PF-Q8040C-O2U Flush 40mm NO 10-60VDC Quick connector PBT
    I4PF-Q8040C-C2U Flush 40mm NC 10-60VDC Quick connector PBT
    I1PF-Q8060N-O3U Flush 60mm NPN NO 10-30VDC Quick connector PBT
    I1PF-Q8060N-C3U Flush 60mm NPN NC 10-30VDC Quick connector PBT
    I1PF-Q8060P-O3U Flush 60mm PNP NO 10-30V Quick connector PBT
    I1PF-Q8060P-C3U Flush 60mm PNP NC 10-30VDC Quick connector PBT
    I1PF-Q8060N-S4U Flush 60mm NPN NO&NC 10-60V Quick connector PBT
    I1PF-Q8060P-S4U Flush 60mm PNP NO&NC 10-60V Quick connector PBT
    I4PF-Q8060C-O2U Flush 60mm NO 10-60VDC Quick connector PBT
    I4PF-Q8060C-C2U Flush 60mm NC 10-60VDC Quick connector PBT
    I1PN-Q8050N-O3U Non-flush 50mm NPN NO 10-30VDC PG13.5 quick connector PBT
    I1PN-Q8050N-C3U Non-flush 50mm NPN NC 10-30VDC PG13.5 quick connector PBT
    I1PN-Q8050P-O3U Non-flush 50mm PNP NO 10-30VDC PG13.5 quick connector PBT
    I1PN-Q8050P-C3U Non-flush 50mm PNP NC 10-30VDC PG13.5 quick connector PBT

    Model Installation type Detection distance Output polarity Voltage Connection mode Shell material Other instructions
    I1PN-Q8050N-S4U Non-flush 50mm NPN NO&NC 10-30VDC PG13.5 quick connector PBT
    I1PN-Q8050P-S4U Non-flush 50mm PNP NO&NC 10-30VDC PG13.5 quick connector PBT
    I4PN-Q8050C-O2U Non-flush 50mm NO 10-60VDC PG13.5 quick connector PBT
    I4PN-Q8050C-C2U Non-flush 50mm NC 10-60VDC PG13.5 quick connector PBT
    I1PN-Q8080N-O3U Non-flush 80mm NPN NO 10-30VDC PG13.5 quick connector PBT
    I1PN-Q8080N-C3U Non-flush 80mm NPN NC 10-30VDC PG13.5 quick connector PBT
    I1PN-Q8080P-O3U Non-flush 80mm PNP NO 10-30VDC PG13.5 quick connector PBT
    I1PN-Q8080P-C3U Non-flush 80mm PNP NC 10-30VDC PG13.5 quick connector PBT
    I1PN-Q8080N-S4U Non-flush 80mm NPN NO&NC 10-30VDC PG13.5 quick connector PBT
    I1PN-Q8080P-S4U Non-flush 80mm PNP NO&NC 10-30VDC PG13.5 quick connector PBT
    I4PN-Q8080C-O2U Non-flush 80mm NO 10-60VDC PG13.5 quick connector PBT
    I4PN-Q8080C-C2U Non-flush 80mm NC 10-60VDC PG13.5 quick connector PBT

    -25℃----+70℃



    CE /  ROHS / UL /  approved
